Wafer Creaming Machine - (CR4) :-

Cream Spreading Machines type CR4 can apply a wide range of creams to all kinds of wafer sheets up to a width of 480 mm. Normally these machines operate on the contact system but can also be supplied with an additional device for creaming by the film system. The spreading head contains a grooved spreading roller and a counter roller spreading roller are heated and thermosta-tically controlled. These two rollers are driven by an infinitely variable speed motor in opposite directions. To obtain the desired quantity of cream, Spreading adjustments:


Technical Data :

Dimensions of wafer sheets 270 x 370 mm (+5mm) & 290 x 460
Width of the spreading roller 455 mm
Wafer Sheet Per Minute 15
Electrical load 1.5 Kw
Size  of the machine (Approximate dimensions of Machine)
Length
Width
Height


2135mm
615mm
1370mm
Weights(Approximate)
Net
with export packing

600 kilos
800 kilos
Shipping space 1.8 cub. meters
